Sony VTC5A 2500mAh 25A-35A Battery Genuine & Tested - Flat Top - Wholesale Discount

Sony

  • $ 6.59

The following quantity discounts will be applied after adding the products to your cart.
Remember that adding other products in the Battery category to your cart will stack to a higher discount!


Genuine Sony US18650VTC5A 2500mAh batteries, also known as the Sony VTC5A or VTC 5A.  These are a great competitor to the Samsung 25R5 and LG HE2, and allow higher current draw than the Sony VTC5.  These batteries are all fresh stock with manufacturing codes within the last few months.  The problem is there are many counterfeits on the market these are guaranteed to be genuine.  We've done extensive testing to be sure they're real so you can be confident you've got the real thing.

Sony VTC5A Official Specifications Datasheet

Quick specs:

  • Chemistry:  NMC
  • Max continuous discharge current:  35A (with temperature cutoff circuitry at 80 degrees C)
  • Max continous discharge current without temperature cut:  25A
  • Style:  Flat top
  • Height:  65mm +/- 0.2mm
  • Diameter:  18.35mm +0.15/-0.2 mm
  • Weight:  47.1g +/-1.5g
  • Nominal capacity: 2600mAh
  • Rated Capacity:  2500mAh
  • Voltage:  3.6V
  • Maximum charge voltage:  4.25V (see specification)
  • Not protected
  • Origin:  Japan/Malaysia
  • Alternate Names:  VCT5A, VCT 5A, VTC5A, US18650VTC5A, US18650VCT5A

⚠ WARNING

The use of any Sony lithium ion rechargeable battery cell as a stand-alone product, including with e-cigarettes, vaporizer pens, and other products, constitutes a DANGEROUS misuse of the battery cells that poses a SERIOUS risk of personal injury or property damage.  Sony does NOT approve using them in this application.  These battery cells should only be used with necessary enclosures and protection circuitry to enable safe usage of the battery cells

Battery safety is very important.  Mistreated batteries can get extremely hot and/or vent which could cause injury.  Always follow the following rules to make sure this doesn't happen.  We are not liable for mistreated batteries.

  • Never completely discharge batteries (below 2.5V under load or 3V unloaded).
  • Charge fully (to 4.2V) before first use.
  • Never use a lot of force on the battery to install
  • Use only high quality battery chargers.
  • Do not expose to heat.
  • Do not connect the positive contact to the negative contact without an appropriate load.
  • Be mindful of the current limits in the specification and never exceed them.
  • Never keep a spare battery loose in a pocket, purse, etc.  Always use protective cases for loose batteries.  If it shorts against a piece of metal it can be very dangerous.
  • Never charge battery 4.3V or above.
  • Do not charge unattended.
  • Do not store your li-ion batteries fully charged for an extended period of time (weeks or more)
  • If you must store battery then do it in a case or individual box in cool and dry place at approximately 3.6V - 3.7V.
  • Never try to charge or discharge li-ion batteries with battery chargers that are not made for Li-ion batteries.

  •
