NCR18650GA flat top 3500 mAh 10A

Panasonic/Sanyo NCR18650GA 18650 Flat Top Battery - 10A 3500mAh

Panasonic

  • $ 5.99

The following quantity discounts will be applied after adding the products to your cart.
Remember that adding other products in the Battery category to your cart will stack to a higher discount!


This is a 3500 mAh 10 A battery and is one of the best batteries we offer.  Testing shows the NCR18650GA vs LG MJ1 competition winner to be the NCR18650GA, although they are both great batteries.

Quick NCR18650GA Specs:

  • Max Continuous Discharging Current: 10A
  • Typical Capacity: 3450 mAh (3350mAh minimum)
  • Style:  FLAT top
  • Dimensions: 66.8mm length (±0.2mm) x 18.55 mm diameter (+0.1 / -0.3 mm)
  • Recommended discharge cut-off voltage: 2.5V
  • Weight:  48g
  • Voltage: 3.6V
  • Full Charge Voltage: 4.2V
  • Charge Current:  1.675A standard
  • Unprotected
  • Origin:  Japan

Battery safety is very important.  Mistreated batteries can get extremely hot and/or vent which could cause injury.  Always follow the following rules to make sure this doesn't happen.  We are not liable for mistreated batteries.



  • Never completely discharge batteries (below 2.5V under load or 3V unloaded).
  • Charge fully (to 4.2V) before first use.
  • Never use a lot of force on the battery to install
  • Use only high quality battery chargers.
  • Do not expose to heat.
  • Do not connect the positive contact to the negative contact without an appropriate load.
  • Be mindful of the current limits in the specification and never exceed them.
  • Never keep a spare battery loose in a pocket, purse, etc.  Always use protective cases for loose batteries.  If it shorts against a piece of metal it can be very dangerous.
  • Never charge battery 4.3V or above.
  • Do not charge unattended.
  • Do not store your li-ion batteries fully charged for an extended period of time (weeks or more)
  • If you must store battery then do it in a case or individual box in cool and dry place at approximately 3.6V - 3.7V.
  • Never try to charge or discharge li-ion batteries with battery chargers that are not made for Li-ion batteries.
