NCR18650GA flat top 3500 mAh 10A

Panasonic/Sanyo NCR18650GA 18650 Flat Top Battery - 10A 3500mAh


  • $ 6.29
  • 4

The following quantity discounts will be applied after adding the products to your cart.
Remember that adding other products in the Battery category to your cart will stack to a higher discount!

This is a 3500 mAh 10 A battery and is one of the best batteries we offer.  It competes with the LG MJ1 in the medium discharge, high capacity category that is great for things like e-bike batteries and electric vehicle batteries.

Panasonic NCR18650GA Datasheet

Note this battery has two different wrapper designs depending on the manufacturing facility, so it may not look like the picture but you can always be assured that we sell authentic NCR18650GA.

Please note that these batteries are not appropriate for most e-cigarette applications due to 10A output.

Quick NCR18650GA Specs:

  • Max Continuous Discharging Current: 10A
  • Typical Capacity: 3450 mAh (3350mAh minimum)
  • Style:  FLAT top
  • Maximum Dimensions:  65.30mm x 18.50 mm diameter
  • Recommended discharge cut-off voltage: 2.5V
  • Weight:  48g
  • Voltage: 3.6V
  • Full Charge Voltage: 4.2V
  • Charge Current:  1.675A standard
  • Unprotected
  • Origin:  China or Japan

Battery safety is very important.  Mistreated batteries can get extremely hot and/or vent which could cause injury.  Always follow the following rules to make sure this doesn't happen.  We are not liable for mistreated batteries.


  • Never completely discharge batteries (below 2.5V under load or 3V unloaded).
  • Charge fully (to 4.2V) before first use.
  • Never use a lot of force on the battery to install
  • Use only high quality battery chargers.
  • Do not expose to heat.
  • Do not connect the positive contact to the negative contact without an appropriate load.
  • Be mindful of the current limits in the specification and never exceed them.
  • Never keep a spare battery loose in a pocket, purse, etc.  Always use protective cases for loose batteries.  If it shorts against a piece of metal it can be very dangerous.
  • Never charge battery 4.3V or above.
  • Do not charge unattended.
  • Do not store your li-ion batteries fully charged for an extended period of time (weeks or more)
  • If you must store battery then do it in a case or individual box in cool and dry place at approximately 3.6V - 3.7V.
  • Never try to charge or discharge li-ion batteries with battery chargers that are not made for Li-ion batteries.
  • Customer Reviews

    Based on 4 reviews
    5 Star
    4 Star
    3 Star
    2 Star
    1 Star
    Write a Review Ask a Question
    • Reviews (4)
    • Questions (0)

    Thank you for submitting a review!

    Your input is very much appreciated. Share it with your friends so they can enjoy it too!
    Walter K.
    United States
    • What device/application do you use this with? Divinity iq

    Panasonic battery

    It lose juice just sitting

    larry t.
    • What device/application do you use this with? ebikes


    I tested all the batteries I bought here. So far all 241 were bang on and again delivered in a timely manner.

    larry t.
    • What device/application do you use this with? ebikes


    it came in a very timely fashion


    Fantastic Capacity for an 18650

    This is probably the biggest capacity 18650 you can find on the market today. (2017) The only known competition to this cell is the LG MJ1 which has similar capacity. There has been a comprehensive review comparing the two where this Sanyo bested the LG. However, one of my concerns is that the cell of this light was not made in Japan like the Panasonics that came before it. I was assured that despite being made in China, these cells share the same quality as the Japanese-made ones but only time will tell. I have several old Panasonics which are over 10 years old, after testing them with a battery analyzer, they still have about 2400+ mAh capacity left after all this time and these are used quite heavily. I would recommend this battery to those looking for high-capacity cells to use in flashlights. For vapers, you may want to check out other cells as the discharge rate of this cell is quite low so not ideal for vaping.
